XPS02ZU

36V (18V X2) LXT® Brushless 6‑1/2" Plunge Circular Saw, AWS®, Tool Only

TECHNOLOGY: Auto-start Wireless System (AWS®) for wireless on/off between the tool and dust extractor
ACCURACY: Dual front and rear bevel supports provide additional rigidity for precise and accurate bevel cuts
SPEED: Variable speed control dial (2,500 - 6,300 RPM) for optimum performance in a variety of materials
DESIGN: Slide lever on base engages the guide rail (sold separately) when bevel cutting for stability
INCLUDES: Wireless unit, 56T carbide-tipped blade and wrench (batteries and charger not included)

VIEW DUST MANAGEMENT OPTIONS

- Download Image as:
- - JPG
- - PNG
- - TIF

OVERVIEW

APPLICATIONS

Makita XPS02ZU Action Shot 1 - Thumbnail

Makita XPS02ZU Action Shot 2 - Thumbnail

Makita XPS02ZU Beauty Shot 1 - Thumbnail

Makita XPS02ZU Beauty Shot 2 - Thumbnail

Makita XPS02ZU Beauty Shot 3 - Thumbnail

FEATURES

Makita XPS02ZU Feature Shot (Auto-Start wireless unit) - Thumbnail

Makita XPS02ZU Feature Shot (bevel adjustment) - Thumbnail

Makita XPS02ZU Feature Shot (bevel positive stops) - Thumbnail

Makita XPS02ZU Feature Shot (blade change lock) - Thumbnail

Makita XPS02ZU Feature Shot (blade change) - Thumbnail

Makita XPS02ZU Feature Shot (blade shaft lock) - Thumbnail

Makita XPS02ZU Feature Shot (guide rail slide lever latch) - Thumbnail

Makita XPS02ZU Feature Shot (hex wrench storage) - Thumbnail

Makita XPS02ZU Feature Shot (line sighting) - Thumbnail

Makita XPS02ZU Feature Shot (lock off button) - Thumbnail

Makita XPS02ZU Feature Shot (plunge depth adjustment) - Thumbnail

Makita XPS02ZU Feature Shot (rail comparison) - Thumbnail

Makita XPS02ZU Feature Shot (range of cut) - Thumbnail

Makita XPS02ZU Feature Shot (speed dial) - Thumbnail

Makita XPS02ZU Feature Shot (stopper button) - Thumbnail

Makita XPS02ZU Feature Shot (tool battery protection system) - Thumbnail

Makita XPS02ZU Feature Shot (tool only) - Thumbnail

Makita XPS02ZU Feature Shot (what's in the box) - Thumbnail

Makita XPS02ZU Feature Shot (wireless unit installation) - Thumbnail

Makita XPS02ZU Feature Shot (wireless unit location) - Thumbnail

Makita XPH07TB Feature Shot (LXT Advantage) - Thumbnail

Makita XPS02ZU Feature Box with text_Accuracy - Thumbnail

Makita XPS02ZU Feature Box with text_Design - Thumbnail

Makita XPS02ZU Feature Box with text_Speed - Thumbnail

Makita XPS02ZU Feature Box with text_Technology - Thumbnail

PRODUCT VIDEOS

AWS®
Makita takes another step toward a truly cordless job site with Auto-Start Wireless System. AWS® uses Bluetooth® technology for wireless power-on and power-off communication between the equipped tool and dust extractor. AWS® is intelligent communication that eliminates cords and excessive noise since the dust extractor runs only when trigger-activated by an AWS® tool. When the trigger is released, the dust extractor powers-down. The Makita AWS® dust extractor (XCV08Z) is powered by two 18V LXT® batteries for maximum performance, and users benefit with an expanding AWS® system that includes cordless tools for concrete, metal and woodworking.

Star Protection Computer Controls™
Makita cordless tools are engineered for industrial applications, and for added protection during the most demanding jobs Makita created STAR Protection Computer Controls™. STAR is communications technology that monitors conditions during use, allowing the tool and battery to exchange data to protect against overloading, overdischarging and overheating. If STAR detects conditions that threaten to overload, overdischarge or overheat the tool or battery, the tool will automatically stop. At that time the user can either restart the tool, change or charge the battery, and put the tool back to work. When you slide a Makita 18V LXT® battery with the STAR symbol onto a Makita tool that has either the STAR symbol or a yellow terminal, you are benefitting from STAR Protection Computer Controls™.

自动变速™
自动变速™is technology that adjusts speed and torque for optimal performance, even in the most demanding applications. During operation, if the tool is put under heavy load, Automatically Speed Change™ detects the added demand and applies more torque and speed to finish the job. Makita cordless tools with Automatic Speed Change™ are engineered to deliver corded performance, without the cord.

About Model

The Makita 36V (18V X2) LXT Brushless 6-1/2” Plunge Circular Saw, with AWS® (XPS02ZU) delivers precise and more accurate cutting when combined with an optional guide rail system (sold separately). The saw and rail system work together to produce accurate cuts with minimal tear-out. The saw combines a powerful Makita-built brushless motor powered by two 18V LXT® batteries with Automatic Speed Change™ Technology, which adjusts cutting speed and torque during the cut for optimum performance.

The XPS02ZU is equipped with Auto-Start Wireless System (AWS®), which uses Bluetooth™ technology for wireless power-on/off communication with the AWS-equipped dust extractor. AWS® is intelligent communication that eliminates cords and reduces noise.

The Saw has a variable speed control dial (2,500 – 6,300 RPM), with soft start and an electric brake for added convenience. It has a large 2-3/16” cutting capacity at 90 degrees, with a bevel capability of -1° to 48° and positive stops at 22.5° and 45°. When used with a rail system (sold separately) a Plunge Circular Saw is a more portable option to a table saw for select applications and is ideal for use on the job site or in a workshop.

It’s part of Makita’s expanding 18V Lithium-Ion system, the world’s largest cordless tool system powered by 18V Lithium-Ion slide-style batteries. Makita 18V Lithium-Ion batteries have the fastest charge times in their categories, so they spend more time working and less time sitting on the charger.

For improved tool performance and extended battery life, Makita created Star Protection Computer Controls™. Star Protection is communication technology that allows the Star Protection-equipped tool and battery to exchange data in real time and monitor conditions during use to protect against overloading, over-discharging and overheating. For increased versatility, the tool can also be powered by Makita 18V LXT® and Compact Lithium-Ion batteries with the star symbol on the battery indicating Star Protection inside.

Features

Powered by two LXT® batteries; X2 LXT® technology delivers more power, performance and run time without the hassles of a cord (batteries not included)
Makita built electronically controlled BL™ Brushless Motor delivers 6,300 RPM for maximum performance and 50% longer run time per charge
X2 LXT® technology delivers up to 125 cuts per charge in 4x8 sheets of 1/2" plywood per charge using two 5.0Ah batteries
Ideal for cutting large wood panels, other wood materials including melamine and MDF, aluminum, and Corian® with optional, material specific blades (includes wood blade, other blades sold separately)
Auto-start Wireless System (AWS®) utilizes Bluetooth® technology for wireless power-on/off communication between tool and optional dust extractor
Variable speed control dial (2,500 - 6,300 RPM) for optimum performance in a variety of materials
Built-in depth stop allows a preliminary first cut of (5/64") 2mm to (7/64") 3mm to be performed prior to cutting through the entire material for clean and splinter-free cutting
Slide lever on saw base designed to engage the optional guide rail (sold separately) when bevel cutting for stability
自动变速™技术调整切割speed and torque during cut for optimum performance
Close to the wall cutting (11/16") for expanded cutting applications
Large cutting capacity (2-3/16" at 90º; and 1-9/16" at 45º)
Bevel capability (-1º to 48º) with positive stops at 22.5º and 45º
Electronic speed control maintains constant speed under load for smooth cutting
Soft start feature for smooth start-ups
Easy-to-set depth adjustment with large scale
Smooth and convenient plunge release lever for operator comfort
Dual front and rear bevel supports provide additional rigidity for precise and accurate bevel cuts
On-board hex wrench for fast and easy blade changes
Locking lever holds the blade in position so that the wrench can be inserted through the hole in the blade case for easier blade installation
Rubberized soft grip handle provides increased comfort on the job
Large 1-7/16" rear dust port directs material away from the operator and easily connects to a vacuum system
Includes a premium 56 tooth ultra thin kerf carbide tipped saw blade (B-57342) ideal for cordless circular saws offering up to 140% more cuts per charge compared to our standard corded plunge saw blade (B-07353)
Optional guide rail system interacts with the saw base to provide smooth, perfect, dead-on straight or bevel cutting
Electric brake for maximum productivity
Compact and ergonomic design at 13-5/8" long; weighs only 11.2 lbs. with batteries (batteries not included) for reduced operator fatigue
Precise straight and 45º bevel cuts as the position of the blade enters the material on the same sight line when using a guide rail
3-stage L.E.D. gauges indicate battery charge levels
Equipped with Star Protection Computer Controls™ to protect against overloading, over-discharging and over-heating
Rapid Optimum Charger and Dual Port Rapid Optimum Chargers communicate with the battery's built-in chip throughout the charging process to optimize battery life by actively controlling current, voltage and temperature (battery and chargers sold separately)
Rapid Optimum Charger and Dual Port Rapid Optimum Chargers have a built-in fan to cool the battery for faster, more efficient charging (battery and charger sold separately)
Makita technology delivers category-leading charge time so the battery spends more time working and less time sitting on the charger (battery and charger sold separately)
Compatible with Makita 18V Lithium-Ion batteries with a Star symbol (batteries sold separately)
3-year limited warranty
Only use genuine Makita batteries and chargers
Optional Accessories: 118" Guide Rail (194367-7), 55" Guide Rail (194368-5), Clamp Set (194385-5), Rip Fence (165447-6), 18V X2 LXT® Lithium-Ion (36V) Brushless Cordless 2.1 Gallon HEPA Filter Dry Dust Extractor/Vacuum, with AWS, Tool Only (XCV08Z)
Saw works with some other competitive guide rails on the market
